1 - TECHNICAL SPECIFICATIONS

Processor
Power
Storage
and transport conditions
Conditions for use

2 - SYMBOLS

700 hPa-1060 hPa

3 - OPERATOR PROFILE

The patient is the operator if he or she:
• changes the batteries
• turns the processor on and off
• switches programs
• connects and disconnects the antenna wire

MISCELLANEOUS

Max dimensions: 50,5 x 50 x 10,6 mm
Weight (with batteries): 11.4 g
Device operating range: 1.8 V to 3.7 V
2 disposable #675 zinc-air batteries
Maximum power consumption: 60 mW
Maximum transmission power: 35 mW
Storage and transport temperature: -20° C to 50° C
Relative humidity: 0 to 90%
Atmospheric pressure: 700 hPa to 1060 hPa
Operating temperature: 5° C to 40° C
Relative humidity: 0 to 90%
Atmospheric pressure: 700 hPa to 1060 hPa
Attention, Please refer to the precautions for use
Waste electrical and electronic equipment
(WEEE)
Type B device, as classified by the French Public Health Code
Processor power button
P675: type "675" (European name) or "PR44" (international name)
zinc-air batteries
+ : Direction to insert the battery
Operating instructions
Min. and max. temperatures to expose to the medical device
Min. and max. humidity to expose to the medical device
Atmospheric pressure
21
Children under the age of 7
should be supervised by an
adult when performing these
actions.
