Exsys EX-1183HMVS-2 Anleitung Seite 11

EX-1183HMVS-2
3. Layout, Connections & Jumper Settings
3.2 Connections
+7V to +48V DC-Connector:
USB 3.2 Gen 1 A-Port:
StdB_SSTX +
StdB_SSTX -
VCC
USB 3.2 Gen 1 B-Port:
StdB_SSTX +
StdB_SSTX -
D-
D+
© Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved
ATTENTION!
Never plug in with force!
Only use a power supply unit that is compatible in
terms of voltage and polarity!
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
GND
D- D+
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
VBus
GND
Attention!
Never plug in with force
or in wrong direction.
Attention!
Never plug in with force
or in wrong direction.
11
English
