S Y N E O S O F T | M E E T I N G M O N T A G E A N L E I T U N G |
I N S T R U C T I O N S H E E T
Meeting geschlossen
| closed
Höhe 2250 mm | Breite 2840 mm |
height 2250 mm | width 2840 mm
2840mm
90°
a) 28 x Scheiben / Washer
b) 20 x Schraube / Screw M6 x 60
c) 4 x Schraube / Screw M6 x 35
d) 12 x Mutter / Nut M6
Schiebetür | Sliding Door
e) 2 x Winkel / Angle
f) 16 x Dübel / Dowel
g) 10 x Pan Head Schraube / Screw 4 x 45
h) 6 x Spax / Wood Screw 4 x 40
i) 10 x Spax / Wood Screw 4 x 30
j) 1 x Schiebetür Führung unten / Sliding Door Foot
k) 1 x Tür Griff / Door Handle Kit
+
+
Glassauger / Suction Cup
2
90°
a) 60 x Scheiben / Washer
b) 44 x Schraube / Screw M6 x 60
c) 4 x Schraube / Screw M6 x 35
d) 12 x Mutter / Nut M6
Schiebetür | Sliding Door
e) 2 x Winkel / Angle
f) 16 x Dübel / Dowel
g) 10 x Pan Head Schraube / Screw 4 x 45
h) 6 x Spax / Wood Screw 4 x 40
i) 10 x Spax / Wood Screw 4 x 30
j) 1 x Schiebetür Führung unten / Sliding Door Foot
k) 1 x Tür Griff / Door Handle Kit
1 Glaswand | 1 Glazed Wall
l) 8 x Schraube / Screw M6 x 20
2 Glaswänd e | 2 Glazed Walls
m) 16 x Schraube / Screw M6 x 20
1
2
S Y N E O S O F T | M E E T I N G
1 x e)
16 x f)
10 x g)
6 x h)
10 x i)
1 x j)
1 x k)
