Ie Configuration; Tcp/Ip Configuration; Configuring Pc (Windows 95/98/Me) - Atlantis Land WebShare 242W Wireless ADSL2+ Router Schnellstartanleitung

•
Password:atlantis
•
IP address (192.168.1.254), Subnet Mask
(255.255.255.0)
•
DHCP Server: enable
•
WAN=PPPoA Routing, VPI=8, VCI=35, VC-Mux
•
SSSID= A02-RA242-W54 , Channel=6,
WEP/WPA=disable

1.6 IE Configuration

Now open IE, go to Instruments menu, select the
Connections tab and select one of the following options:
•
Never use remote connection
•
Use
connection isn't available

1.7 TCP/IP Configuration

Configuring PC (Windows 95/98/ME)

1. Go to Start / Settings / Control Panel. In the Control
Panel, double-click on Network and choose the
Configuration tab.
2. Select TCP / IP -> NIC Compatible, or the name of
any Network Interface Card (NIC) in your PC.
3. Click Properties.
4. Select the IP Address tab. In this page, click the
Obtain an IP address automatically radio button.
5. Then select the DNS Configuration tab.
remote connection
ENGLISH
if another network
28
