• Finally connect the APPUA90AUT to domestic power
outlet.
Note: Avoid placing any heavy object on the APPUA90AUT. Once
installed please make sure the APPUA90AUT fields "Tip No.", "Voltage "and
"Compatibility" coincides exactly with the model of your laptop. To do this
please refer to the table shown in Fig.1
No VOLTAGE
1 18,5 V
2 19 V
4 19 V
5 19 V
6 19 V
9 19,5 V
11 20 V
12 19 V
14 15 V
15 16 V
16 18,5 V HP
24 16 V
Fig.1
LABEL MEASURES
18.5V/01
4.8 x 1.7 mm
19V/02
5.5 x 1.7 mm
19V/04
5.5 x 2.5 mm
5.5 x 3.0 mm
19V/05
(with 1.4mm Pin)
6.5 x 4.4 mm
19.5V/06
(with 1.4mm Pin
7.4 x 5.0 mm
19.5V/09
(with 1.4mm Pin)
7.9 x 5.5 mm
20V/11
Straight with pin
19V/12
5.5 x 2.1 mm
6.3 x 3.0 mm
15V/14
Straight
16V/15
5.5 x 2.5 mm
7.4 x 5.0 mm
18.5V/16
(with 1.4mm Pin)
6.5 x 4.4 mm
16V/24
(with 1.4mm Pin)
COMPATIBILITY
HP
DELL, ACER
ACER, COMPAQ, LENOVO,
HP, GATEWAY, FUJISTU,
TOSHIBA, IBM, ADVENT
SAMSUNG
SONY
DELL
IBM
ASUS,ACER
TOSHIBA,ACER
IBM
HP,COMPAQ
SONY,FUJISTSU,SAMSUNG
