English
Package content
• Media converter
• Power supply
• User manual
Safety instructions
• This product is suitable for indoor application only.
• Put on the dust cover of fiber interface when not used.
• It is forbidden to look into the fiber.
Installation
• SFP interface
Slide the optional SFP module into the SFP slot and push until you hear a
click. Connect a fibre cable from the SFP module to the fibre network. The fibre
connections must be matched transmit socket (TX) to receive socket (RX).
• TP interface
Connect a TP cable from the 10GBase-T network to the RJ-45 port on the
media converter.
• Power
Connect the power adapter to the media converter and check that the Power
LED lights up. The LEDs will light up when all the cable connections are
correctly installed.
LED Status
PWR On
On
FX Link/Act
Blink
SD On
On
10G
Off
TX Link On
Description
Power is on and normal.
Connection status display for fibre link.
"On" indicates that the fibre link has a correct
connection.
Active status display of fibre link.
"Blink" indicates that packets go through FX.
Fibre signal is detected.
Transfer rate of TP interface is 10 Gbps.
Transfer rate of TP interface is 10 Mbps.
Connection status display for TP link.
"ON" indicates that the TP link is has a correct
connection.
-3-
