English
Safety instructions
• Protect the product against moisture
• Protect the product against direct sunlight
Hardware Installation
Note: For the installation of the hardware all devices should be turned off.
1.
Connect the DisplayPort cable between the DisplayPort output of the
computer and the DisplayPort input of the KVM.
2. Connect the USB 5 Gbps cable to the USB-A port of the computer and to the
USB-C™ upstream port of the KVM.
3.
Connect the DisplayPort monitor to the DisplayPort output of the KVM.
4.
Plug in the USB power cable to a USB Type-A port or power supply.
5. Now connect the cables of the mouse and keyboard to the KVM switch.
6. Connect other USB devices to the USB 5 Gbps Hub if necessary.
7. Turn on all connected devices.
Operation
By using the button on the top you can switch between the different video
sources.
Support Delock
If you have further questions, please contact our customer support
support@delock.de
You can find current product information on our homepage: www.delock.com
Final clause
Information and data contained in this manual are subject to change without
notice in advance. Errors and misprints excepted.
Copyright
No part of this user manual may be reproduced, or transmitted for any purpose,
regardless in which way or by any means, electronically or mechanically, without
explicit written approval of Delock.
Edition: 09/2023
