Installation
2B
W-C
WARNING
• Make sure that mounting screws are anchored into the center of the studs. Use of a stud finder is
highly recommended.
• When installing wall mounts onto a concrete masonry unit (also known as a CMU or "cinder
block"), verify that the actual concrete thickness is at least 35 mm (1-3/8") in order to hold the
concrete anchors. DO NOT DRILL INTO MORTAR JOINTS! Be sure to mount the assembled wall-
mount plate with the included concrete anchors, washers and anchor bolts onto solid sections
of the blocks. The solid sections can generally be found 25 mm (1") toward the middle of the
block from either end. An electric drill on a slow setting is suggested to drill the hole rather than a
hammer drill, so as to avoid breaking out the back of the hole when entering a hollow section.
• Installers must verify that the supporting surface will safely support the combined load of the
equipment and all attached hardware and components.
• Installers are responsible to provide hardware for other types of mounting situations.
W-A
W-B
W-C
W-A
5
