Adjusting the bevel angle (Fig. B, F)
1. Loosen the bolt (18), using the hex key (15).
2. Adjust the baseplate (9) to the desired
position (0°- 45°). The sawing angle (bevel)
can be read on the scale (7).
3. Tighten the bolt (7), using the hex key (15).
It is possible to store the hex key onto the
machine, as shown on Fig. B.
Adjusting the pendulum action (Fig. A)
The pendulum action switch is used to set the
way in which the teeth of the saw blade grip the
material. The pendulum action switch can be set
to 4 positions:
0 - No pendulum action
1 - Small pendulum action
2 - Medium pendulum action
3 - Large pendulum action
The required pendulum action can be determined
by practical testing, although the following
instructions can be observed:
• Soft material (wood, plastics etc.): set the
pendulum to level II or III. For a finer and
cleaner saw cut, use pendulum level 0 or I.
• Thin material, use pendulum level 0.
• Hard material (steel etc.): set the pendulum to
level 0.
• Curves: set pendulum to level 0.
Plunge cutting (Fig. H)
Plunge cutting may only be used on soft
materials such as wood, aerated concrete,
gypsum plaster boards, etc. However, this
requires a certain practise and is only possible
with short saw blades.
1. Place the saw onto the workpiece and switch
it on.
2. Ensure that the bottom edge of the footplate
rests on the workpiece surface as shown on
Fig. H.
3. Slowly saw into the workpiece at an angle,
moving the saw to a vertical position and
continue to saw along the cutting line.
4. Switch the saw off and lift off the workpiece
when the work is complete.
Optimum use
• Clamp the workpiece. Use a clamping device
for small workpieces.
• Draw a line to define the direction in which to
guide the saw blade.
• Firmly hold the machine by the grip.
• Set the sawing speed.
• Set the mitre angle.
• Switch on the machine.
• Wait until the machine has reached full speed.
• Place the saw shoe on the workpiece.
• Slowly move the machine along the pre-
drawn line, firmly pressing the saw shoe
against the workpiece.
• Do not apply too much pressure on the
machine. Let the machine do the work.
• Switch off the machine and wait for the
machine to come to a complete standstill
before putting the machine down.
5. MAINTENANCE
Before cleaning and maintenance,
always switch off the machine and
remove the battery pack from the
machine.
Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that
the ventilation openings are free of dust and
dirt. Remove very persistent dirt using a soft
cloth moistened with soapsuds. Do not use any
solvents such as gasoline, alcohol, ammonia,
etc. Chemicals such as these will damage the
synthetic components.
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be
collected at the appropriate recycling
locations.
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/EC for
Waste Electrical and Electronic Equipment and its
implementation into national right, power tools that
are no longer usable must be collected separately and
disposed of in an environmentally friendly way.
9
