control over the power tool.
• Use clamps or another practical way to
secure and support the workpiece to a
stable platform.
Holding the workpiece by hand or against
your body leaves it unstable and may lead to
loss of control.
2. MACHINE INFORMATION
Intended use
The machine is intended for sawing wood, metal,
plastics, ceramics, rubber, etc. to any required
size and in any required shape, while keeping
the baseplate resting firmly on the workpiece. A
suitable saw blade must always be used.
Technical specifications
Model No.
Rated voltage
No load speed
Saw stroke
Max. saw capacity wood 0°
Max. saw capacity steel 0°
Weight
Sound pressure level LPA
Sound power level LWA
Vibration 'sawing sheet metal'
Vibration 'sawing plywood'
Only use the following batteries of the FERM
POWER 20V battery platform. Using any other
batteries could cause serious injury or damage
the tool.
CDA1136
20V, 2Ah Lithium-Ion
CDA1138
20V, 4Ah Lithium-Ion
The following charger of the can be used to
charge these batteries.
CDA1137
Quick charger
The batteries of the FERM POWER 20V battery
platform are interchangeable with all the FERM
POWER 20V battery platform tools.
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardized test given in
EN 62841; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
• Using the tool for different applications,
or with different or poorly maintained
accessories, may significantly increase the
exposure level.
• The times when the tool is switched off or
when it is running but not actually doing the
job, may significantly reduce the exposure
level.
Protect yourself against the effects of vibration
by maintaining the tool and its accessories,
keeping your hands warm, and organizing your
work patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
JSM1036
20V
1. Lock-off button
0-2500/min
2. On/off switch
25mm
3. Handle
50mm
4. Battery (not included)
8mm
5. Battery unlock button
1.85 kg
6. Pendulum action switch
82.0 dB(A), K=3dB(A)
7. Scale for bevel angle
93.0 dB(A), K=3dB(A)
8. Baseplate cover
5.459 m/s
K=1.5 m/s
2
2
5.658 m/s
K=1.5 m/s
2
2
9. Baseplate
10. Guide roller
11. Laser switch
12. Guard
13. Clamping lever
14. Wing bolts for parallel guide
15. Hex key
16. Chuck
17. Saw blade
18. Bolt for baseplate
19. Parallel guide
20. Laser
21. Cutting mark
22. Laser adjustment screw
7
