GUDE Systems Expert Power Control 8035 Serie Anleitung Seite 61

Spezifikationen
epc8035PowerReactive
epc8035AbsEnergyReactive
epc8035AbsEnergyActiveResetta-
ble
epc8035AbsEnergyReactiveReset-
table
epc8035ResetTime
epc8035ForwEnergyActive
epc8035ForwEnergyReactive
epc8035ForwEnergyActiveReset-
table
epc8035ForwEnergyReactiveRe-
settable
epc8035RevEnergyActive
epc8035RevEnergyReactive
epc8035RevEnergyActiveResetta-
ble
epc8035RevEnergyReactiveReset-
table
epc8035ResidualCurrent
epc8035ResidualCurrentRMS
epc8035ResidualCurrentDC
epc8035LineSensorName
epc8035OVPIndex
epc8035OVPStatus
epc8035spActivePowerChan
epc8035spPowerIndex
epc8035spChanStatus
epc8035spAbsEnergyActive
epc8035spPowerActive
epc8035spCurrent
epc8035spVoltage
epc8035spFrequency
epc8035spPowerFactor
epc8035spPangle
epc8035spPowerApparent
epc8035spPowerReactive
epc8035spAbsEnergyReactive
61
Expert Power Control 8031/8035
.83.1.5.1.2.1.11.x
L Line Mean Reactive Power
.83.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.83.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all resetta-
ble counter.
.83.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.83.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.83.1.5.1.2.1.16.x
Forward Active Energy counter.
.83.1.5.1.2.1.17.x
Forward Reactive Energy counter.
.83.1.5.1.2.1.18.x
Resettable Forward Active Energy counter.
.83.1.5.1.2.1.19.x
Resettable Forward Reactive Energy counter.
.83.1.5.1.2.1.20.x
Reverse Active Energy counter.
.83.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.83.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.83.1.5.1.2.1.23.x
Resettable Reverse Reactive Energy counter.
.83.1.5.1.2.1.24.x
Actual Residual Current on Power Channel. According Type A IEC
60755. Only visible on models that support this feature.
.83.1.5.1.2.1.25.x
Actual Residual Current RMS on Power Channel. According Type B IEC
60755. Only visible on models that support this feature.
.83.1.5.1.2.1.26.x
Actual Residual Current DC on Power Channel. According Type B IEC
60755. Only visible on models that support this feature.
.83.1.5.1.2.1.100.x
A textual string containing name of a Line Sensor
.83.1.5.2.1.1.x
None
.83.1.5.2.1.2.x
shows the status of the built-in Overvoltage Protection
.83.1.5.5.1.0
Number of Single Port Power Channels. Value is zero on EPC 8220 se-
ries.
.83.1.5.5.2.1.1.x
Index of Single Port Power Channel entries. Indices 0-5 mean Ports A1
to A6, 6-11 are Ports B1 to B6.
.83.1.5.5.2.1.2.x
0 = data not active, 1 = data valid
.83.1.5.5.2.1.3.x
Absolute Active Energy counter.
.83.1.5.5.2.1.4.x
Active Power
.83.1.5.5.2.1.5.x
Actual Curent on Power Channel.
.83.1.5.5.2.1.6.x
Actual Voltage on Power Channel
.83.1.5.5.2.1.7.x
Frequency of Power Channel
.83.1.5.5.2.1.8.x
Power Factor of Channel between -1.0 and 1.00
.83.1.5.5.2.1.9.x
Phase Angle between Voltage and L Line Current between -180.0 and
180.0
.83.1.5.5.2.1.10.x
L Line Mean Apparent Power
.83.1.5.5.2.1.11.x
L Line Mean Reactive Power
.83.1.5.5.2.1.12.x
Absolute Reactive Energy counter.
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Unsigned32 RO
Unsigned32 RO
Unsigned32 RO
OCTETS RW
Integer32 RO
INTEGER RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
© 2021 GUDE Systems GmbH
