GB
SAFETY INSTRUCTIONS FOR BATTERIES
• Do not attempt to revive batteries or rechargeable batteries by heating or similar measures. Primary batteries
must not be recharged as this can lead to electrolyte leakage, explosion or fire.
• Do not immerse batteries in water and store them in a dry, cool place, not a damp one.
• Do not throw batteries into a fire, do not open them nor solder or weld them yourself.
• Do not short-circuit batteries.
SCOPE OF DELIVERY
Check the delivery for completeness and perfect condition.
In the case of missing parts or damage:
• do not mount the unit!
• do not put the unit into operation!
• make a complaint to the supplier.
The deliver consists of:
• Product
• Instructions
• Power supply plug + 95cm USB cable
TECHNICAL DATA
Work lamp
• Output: 30W LED
• Illuminant: SMD LED´s
• Luminous flux: 3000lm
• Luminous efficacy: 100lm/W
• Colour temperature: 7000K
• Colour rendering index (Ra/CRI): ≥ 80
• LED service life: 30.000h
• Beam angle: 120°
• IP protection class: IP54
• IP protection class (in charging state): IP20
• Protection class: III (S5)
• Ambient temperature: -10°C - 40°C
• Dimensions W x H x D: 240 x 231 x 160mm
• Weight: 1032g
• Battery: 3,7V / 8000mAh (4x2000mAh) /
Lithium polymer batteries (18650) / 29,6Wh
• USB: 5,0V DC, 1,0A
OPERATION
• Charging: Before (first) use, fully charge the product until the battery indicator lights up completely
(Note: Carry out loading only frost-free!)
• Charging time: 4,5 hours
• Running time: 2 hours (3000lm) / 4 hours (1500lm)
• 1x press: half power (1500lm)
• 2x press: full power (3000lm)
• 3x press: Off
CLEANING
• Allow the luminaire to cool down sufficiently!
• Before cleaning, unplug the product from the power point or disconnect it from the mains supply!
• Clean with a dry or slightly moist, clean, lint-free cloth and a mild detergent if required. Do not use cleaners that
contain abrasives or solvents.
• Never spray for cleaning or use a steam pressure cleaner, as this may damage the insulation and seals!
10
Power supply unit (power supply plug in combination
with USB cable included in delivery)
• Manufacturer: Yuyao City Huazhang Electrical Factory,
No.76, Fangshan, Lincheng Village, Linshan Town,
YuYao City, ZheJiang, P.R. China; Trade Registration
Number: 92330281MA2EPDRW90
• Model ID: HZ-G0502000USB
• Input voltage: 230V~
• Input AC frequency: 50Hz
• Output voltage: 5.0V DC
• Output current: 2.0A
• Output power (Po): 10.0W
• Average efficiency during operation: 78.74%
• Efficiency at low load (10%): 74.24%
• Power consumption at no load: 0.055W
• Protection class: II (S6)
