Commissioning of Centronic

For the setting of limit positions and configurations please
refer to the instructions for the Centronic receiver.
Explanation of symbols

Programming the transmitter

Putting the receiver into programming mode
Follow the Assembly and Operating Instructions for the re-
ceiver.
• Switch off the power supply to the receiver for 5 seconds, then switch it
back on.
or
• Operate the programming button or the radio switch of the receiver.
The receiver is now in programming mode for 3 minutes.
22 - en
Up/retract button
STOP button
Down/extend button
Programming button (on the transmitter
Receiver confirms once or multiple times by
"clicking" or "shifting"
)
