32 TUBE ULTRAGAIN MIC200
Specifi cations
Audio Inputs
XLR Input
Connector
Type
Impedance
Max. input level
¼" TRS Input
Connector
Type
Impedance
Max. input level
E.I.N. 1 (20 Hz - 20 kHz)
@ 0 Ω source resistance
@ 150 Ω source resistance
@ 600 Ω source resistance
balanced / unbalanced
transformerless, DC-decoupled input
approx. 2 kΩ
+7 dBu / -20 dB with pad
balanced / unbalanced
transformerless, DC-decoupled input
approx. 1 MΩ
+16 dBu / -20 dB with pad
-125.5 dBu / -128.5 dBu A-weighted
-124 dBu / -126.8 dBu A-weighted
-120 dBu / -122.7 dBu A-weighted
Audio Outputs
XLR connector + ¼" TRS jack
Connectors
balanced / unbalanced
Type transformerless, DC-decoupled output
approx. 700 Ω balanced,
Impedance
approx. 350 Ω unbalanced
Max. output level approx. +26 dBu @ 100 kΩ
System Data
Signal-to-noise ratio 90 dB A-weighted @ -28 dBu input level
Frequency Response
Mic input <10 Hz to 47 kHz (±3 dB)
Line input <10 Hz to 55 kHz (±3 dB)
Function Controls
GAIN variable (+26 dB to +60 dB)
OUTPUT variable (-∞ to +10 dB)
selection of various preamp settings for
Preamp mode control
microphone and instruments
Quick Start Guide 33
