Left Side View - Monster Semruk S7 V9.2 Benutzerhandbuch

EN
3. Woofer Speaker
The woofer speaker is to reproduce low-pitched audio frequency.
4. USB 3.2 Gen 2 Port
USB 3.2 Gen 2, the SuperSpeed USB 10Gbps, supports high-speed data transfer
for the connected devices, such as storage devices, hard drives, or video cameras.
5. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.

Left Side View

1. Thunderbolt (Type-C) port (optional)
Thunderbolt™ 4, optionally supports USB4, PCIe, HDMI™, DisplayPort
connection; 8K display monitor output; up to 40Gbps transfer rate.
Supports maximum 5V/3A portable charging power output when AC power is
connected. However, the maximum portable charging power limitation may up to
5V/1.5A while only battery DC power is connected.
2. Combo Audio Port
A port for a headset, microphone, or headset with microphone.
> vThe Combo Audio Port supports 4-Pole 3.5mm headphone jack.
16
