Using the TV-IP672PI with an Injector (TPE-113GI)
Non-PoE
1. Connect the power adapter to the TPE-113GI and then to a power outlet
2. Connect a network cable from the TV-IP672PI to the TPE-113GI's PWR+DATA OUT port
3. Connect a network cable from a switch or router (e.g. TEW-639GR) to the TPE-113GI's DATA IN
port.
Note:
1. To manage m ultiple cameras and for more advanced features, please install the SecurView Pro
software. Install the software by clicking Install SecurView in the Autorun window and refer to the
SecurView Pro User's Guide on the CD for more information.
2. Two User's Guides are included – one for the camera and one for the complementary management
software.
All manuals and user guides at all-guides.com
TPE-113GI
Non-PoE
PoE
4
TV-IP672PI
