- Seite 1 All manuals and user guides at all-guides.com -HW&RQ Z LZ ,QGXVWULDO 56 WR 56 6HULDO &RQYHUWHU 4XLFN ,QVWDOODWLRQ *XLGH ZZZNRUHQL[FRP 9...
-
Seite 2: Product Features
High Speed 921.6Kbps 3000V RS-485/422 isolation protection RX biasing and line terminator selection Easy Configure without power resetting -40~70 C wide operating temperature JetCon 2201-w / JetCon 2201-iw Industrial RS-232 to RS-422/485 serial converter Quick Installation Guide Package Checklist v 1.0 www.korenix.com V1.0... -
Seite 3: Systeminstallation
All manuals and user guides at all-guides.com System Installation 1. Mounting the Unit – DIN Rail Din-Rail mount: screw up the DIN rail mount kit with 4 screws and mount JetCon 2201 on the DIN Rail. Insert the flat screw driver into the bottom of clip to loosen the clip from the track... - Seite 4 All manuals and user guides at all-guides.com DIP Switch RS-232 2201i RS-232 to RS-422/485 Converter Output Voltage: DC 24V/1A AC Input Switching Power Supply UL Certified RS-422/485-4w RS-485-2w 12-48V Earth Ground Power Input Range DC 12V~48V 4. Connecting the serial interface JetCon 2201 supports RS-232 converts to RS-422, RS-485 4-wire and 2-wire.
- Seite 5 All manuals and user guides at all-guides.com 4.2 RS-422/485 configuration The JetCon 2201-w/2201-iw provides one 5-pin DIP-switch to select the RS-422/485 mode and also provides 120 ohm line terminator selection. The configuration of DIP-switch shows as following table. Be sure the DIP-switch is configured as right mode before make the RS-422 or RS-485 connection.
- Seite 6 All manuals and user guides at all-guides.com RS-422 4-wire Peer to Peer Architecture: Point to Point Baud Rate: 300~921.6 Kbps Distance: 4000 feet RS-232 to RS-422 4-wire Point to Point DIP Switch RS-232 DIP Switch RS-232 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w RS-485-2w...
- Seite 7 All manuals and user guides at all-guides.com RS-485 2-wire multi-drop Architecture: Master-Slave Mode. Max. Distance: 4000 feet Baud Rate: 300~921.6 Kbps Max. Node: 32 nodes RS-232 to RS-485 2-wire Multi-Drop DIP Switch RS-232 DIP Switch RS-232 DIP Switch RS-232 2201i 2201i 2201i RS-232 to RS-422/485 Converter...
- Seite 8 RS-422/RS-485 RS-232 RS-422/485 RS-232 RS-422/485 921.6Kbps RS-485/422 3000V -40~70 JetCon 2201-w / JetCon 2201-iw Industrial RS-232 to RS-422/485 serial converter JetCon 2201 1 Quick Installation Guide v 1.0 www.korenix.com V1.0 74mm (W) x 24.7mm(H) x 99mm (D) DIP Switch RS-232...
- Seite 9 All manuals and user guides at all-guides.com JetCon 2201 DIP Switch RS-232 2201i 3.5mm RS-232 to RS-422/485 Converter 7.00mm RS-422/485-4w RS-485-2w 12-48V JetCon 2201 DC24V 12V 48V...
- Seite 10 All manuals and user guides at all-guides.com DIP Switch RS-232 2201i RS-232 to RS-422/485 Converter : DC 24V/1A RS-422/485-4w RS-485-2w 12-48V Power Input Range DC 12V~48V JetCon 2201 RS-232 RS-422, RS-485 4-wire 2-wire RS-232 Female DB-9 RS-422/485 RS-232 (DB-9) Pin No. Carrier Detect Transmit Data Receive Data...
- Seite 11 All manuals and user guides at all-guides.com 4.2 RS-422/485 JetCon 2201-w/2201-iw 5-pin DIP RS-422/485 120 ohm RS-422 RS-485 RS-422 RS-485 4-wire RS-485 2-wire RX +/- Terminator (120Ω) RX+/- Biasing (150KΩ) RX+/- Biasing (1KΩ) 2 3 4 5 multi-drop RS-485 JetCon 2201...
- Seite 12 All manuals and user guides at all-guides.com RS-422 4-wire Peer to Peer : 300~921.6 Kbps : 4000 feet RS-232 RS-422 4-wire Point to Point DIP Switch RS-232 DIP Switch RS-232 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w RS-485-2w 12-48V...
- Seite 13 All manuals and user guides at all-guides.com RS-485 2-wire multi-drop : Master-Slave Mode. : 4000 feet : 300~921.6 Kbps : 32 nodes RS-232 RS-485 2-wire Multi-Drop DIP Switch RS-232 DIP Switch RS-232 DIP Switch RS-232 2201i 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w...
-
Seite 14: Einleitung
3000V RS-485/422 Isolationsschutz RX biasing und Abschlußwiderstand auswählbar Leichte Konfiguration ohne Stromabschaltung -40~70 C weiter Betriebstemperaturbereich Packungsinhalt JetCon 2201-w / JetCon 2201-iw Industrial RS-232 to RS-422/485 serial converter Quick Installation Guide Die JetCon 2201 Serie wird mit v 1.0 www.korenix.com folgenden Positionen ausgeliefert V1.0... -
Seite 15: Befestigung - Din Schiene
All manuals and user guides at all-guides.com System Installation 1. Befestigung – DIN Schiene DIN-Schienenbefestigung: Schrauben Sie das DIN Schienenbefestigungs-Kit mit 4 Schrauben an und klemmen Sie das JetCon 2201 an die DIN-Schiene Drücken Sie mit einem Schlitzschraubendreher auf die Unterseite des Clip und lösen Sie den Clip von der Schiene. -
Seite 16: Definition Der Rs-232 Pinbelegung (Db-9 )
All manuals and user guides at all-guides.com DIP Switch RS-232 2201i RS-232 to RS-422/485 Converter Output Voltage: DC 24V/1A AC Input Switching Power Supply UL Certified RS-422/485-4w RS-485-2w 12-48V Earth Ground Power Input Range DC 12V~48V 4. Verbinden des seriellen Interface JetCon 2201 unterstützt RS-232 Konvertierung nach RS-422, RS-485 als 4- und 2-Draht. -
Seite 17: Beschreibung
All manuals and user guides at all-guides.com 4.2 RS-422/485 Konfiguration Das JetCon 2201-2/2201-iw besitzt einen 5-poligen DIP-Schalter um den RS-422/485 Modus und ebenso den 120 Ohm Abschlußwiderstand auszuwählen. Die Konfiguration des DIP-Schalters zeigt die folgende Tabelle. Stellen Sie sicher, daß der DIP-Schalter auf den richtigen Modus eingestellt ist, bevor Sie die RS-422 oder RS-485 verbinden. - Seite 18 All manuals and user guides at all-guides.com RS-422 4-Draht Peer to Peer Architektur: peer to peer Baud Rate: 300~921.6 Kbps Max.Entfernung: 4000 feet RS-232 to RS-422 4-wire Point to Point DIP Switch RS-232 DIP Switch RS-232 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w RS-485-2w...
- Seite 19 All manuals and user guides at all-guides.com RS-485 2-Draht multi-drop Architektur: Master-Slave Modus. Max. Entfernung: 4000 feet Baud Rate: 300~921.6 Kbps Max. Node: 32 Nodes RS-232 to RS-485 2-wire Multi-Drop DIP Switch RS-232 DIP Switch RS-232 DIP Switch RS-232 2201i 2201i 2201i RS-232 to RS-422/485 Converter...
- Seite 20 C température de fonctionnement Liste du Pack de livraison Les séries de JetCon 2201 sont livrées avec les articles suivants: JetCon 2201-w / JetCon 2201-iw Industrial RS-232 to RS-422/485 serial converter Quick Installation Guide JetCon 2201 x1 Guide Installation Rapide x1 v 1.0...
- Seite 21 All manuals and user guides at all-guides.com Installation de système 1. Montage de l’Unité – Rail DIN Montage sur Rail DIN: serrez le kit de montage sur rail DIN avec 4 visses et installez le JetCon 2201 sur le Rail DIN. Insérer le tournevis plat dans le fond de l’agrafe pour détacher l’agrafe.
- Seite 22 All manuals and user guides at all-guides.com DIP Switch RS-232 2201i RS-232 to RS-422/485 Converter Voltage Sorti: DC 24V/1A AC Entrée Switching Power Supply UL Certified RS-422/485-4w RS-485-2w 12-48V Raccordement Masse Variation de la Tension d’Entrée DC 12V~48V 4. Connexion de l’interface série Le JetCon 2201 supporte le protocole RS-232 et le convertis en RS-422, RS-485 4-fils et 2-fils.
- Seite 23 All manuals and user guides at all-guides.com 4.2 Configuration RS-422/485 configuration Le JetCon 2201-w/2201-iw propose un DIP Switch de 5 pôles pour sélectionner le mode RS-422/485. Il propose également la sélection de la résistance de fin de ligne 120 ohms.
- Seite 24 All manuals and user guides at all-guides.com RS-422 4-fils Pair-à-Pair Architecture: Point-à-Point Taux de Baud: 300~921.6Kbps Distance: 4000 feet RS-232 vers RS-422 4-fils Point-à-Point DIP Switch RS-232 DIP Switch RS-232 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w RS-485-2w 12-48V...
- Seite 25 All manuals and user guides at all-guides.com RS-485 2-fils multi-drop Architecture: Mode Maître-Esclave Distance Max.: 4000 feet Taux de Baud: 300~921.6 Kbps Nœud Max: 32 nœuds RS-232 vers RS-485 2-fils Multi-Drop DIP Switch RS-232 DIP Switch RS-232 DIP Switch RS-232 2201i 2201i 2201i...
-
Seite 26: Características
Fácil configuración sin necesidad de reiniciar el equipo Amplio rango de temperatura: -40~70 Contenido del Embalaje El JetCon 2201 se suministra con los JetCon 2201-w / JetCon 2201-iw Industrial RS-232 to RS-422/485 serial converter siguientes elementos: Quick Installation Guide JetCon 2201 x 1 v 1.0... - Seite 27 All manuals and user guides at all-guides.com Instalación 1. Montaje de la unidad – Carril DIN Fijar el accesorio DIN mediante los 4 tornillos suministrados Para desmontar el equipo del carril utilice un destornillador para presionar en la parte inferior del clip de sujección 2.
- Seite 28 All manuals and user guides at all-guides.com DIP Switch RS-232 2201i RS-232 to RS-422/485 Converter Output Voltage: DC 24V/1A AC Input Switching Power Supply UL Certified RS-422/485-4w RS-485-2w 12-48V Earth Ground Power Input Range DC 12V~48V 4. Conexión del interface serie El JetCon permite la conversión de RS232 a RS422, RS485 a 4 hilos y RS485 a 2 hilos, siendo el puerto RS232 del tipo DB9 y del tipo regleta extraíble para el RS422/485.
- Seite 29 All manuals and user guides at all-guides.com muestra las distintas posibilidades, asegúrese de que la configuración es correcta antes de realizar la conexión RS422/485. Description RS-422 RS-485 4-wire RS-485 2-wire RX +/- Terminator (120Ω) RX+/- Biasing (150KΩ) RX+/- Biasing (1KΩ) 2 3 4 5 En una red RS485 con múltiples dispositivos no activos, todos los nodos se encuentran en modo recepción.
- Seite 30 All manuals and user guides at all-guides.com RS-422 4-hilos Punto a Punto, Arquitectura: Punto a Punto Velocidad: 300~921.6 Kbps Distancia: hasta 1300mt. RS-232 vers RS-422 4-fils Point-à-Point DIP Switch RS-232 DIP Switch RS-232 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w RS-485-2w 12-48V...
- Seite 31 All manuals and user guides at all-guides.com RS-485 2-hilos multipunto Arquitectura Mestro-Esclavo Distancia: hasta 1300mt. Velocidad: 300~921.6 Kbps Máximo nº de nodos: 32 nodos RS-232 to RS-485 2-wire Multi-Drop DIP Switch RS-232 DIP Switch RS-232 DIP Switch RS-232 2201i 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter...
-
Seite 32: Основные Характеристики
Подключение встроенных терминальных резисторов Простая настройка без перезапуска питания Широкий диапазон температуры эксплуатации -40~70 Комплектность В комплект поставки входят: JetCon 2201-w / JetCon 2201-iw Industrial RS-232 to RS-422/485 serial converter JetCon 2201 – 1 шт Quick Installation Guide Руководство по быстрому... -
Seite 33: Установка
All manuals and user guides at all-guides.com Установка 1. Крепление на DIN-рейку Закрепите комплект для монтажа на DIN-рейку 4 винтами к JetCon 2201 и установите его на DIN-рейку. Для ослабления зажима вставьте отвертку в его нижнюю часть. 2. Крепление на монтажную панель DIP Switch RS-232 2201i... - Seite 34 All manuals and user guides at all-guides.com DIP Switch RS-232 2201i RS-232 to RS-422/485 Converter Выходное напряжение: DC 24В/1A AC вход Switching Power Supply UL Certified RS-422/485-4w RS-485-2w 12-48V Заземление Диапазон напряжения DC 12V~48V 4. Подключение последовательного интерфейса JetCon 2201 поддерживает преобразование RS-232 в RS-422, RS-485 4-провода 2-провода.
- Seite 35 All manuals and user guides at all-guides.com 4.2 Конфигурация RS-422/485 JetCon 2201-w/2201-iw имеет один DIP-переключатель 5-pin для выбора режима RS-422/485, а также – для подключения 120 Ом терминальных сопротивлений. Конфигурация DIP-переключателя указана в таблице. Убедитесь в правильной конфигурации перед использованием подключения RS-422 или RS-485.
- Seite 36 All manuals and user guides at all-guides.com RS-422 4-проводное подключение точка-точка (Peer to Peer) Архитектура: точка-точка Скорость передачи: 300~921.6 кбит/с Расстояние: 1200 метров RS-232 в RS-422 4-проводное подключение точка-точка DIP Switch RS-232 DIP Switch RS-232 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w RS-485-2w...
- Seite 37 All manuals and user guides at all-guides.com RS-485 2-проводное многоабонентное подключение Архитектура: Master-Slave. Расстояние: 1200 метров Скорость передачи: 300~921.6 кбит/с Максимальное количество абонентов: 32 RS-232 в RS-485 2-проводное многоабонентное подключение DIP Switch RS-232 DIP Switch RS-232 DIP Switch RS-232 2201i 2201i 2201i RS-232 to RS-422/485 Converter...
- Seite 38 自動RS-232 対 RS-422/485変換 自動ボーレートと方向コントロール 高速 ： 921.6Kbps 3000V RS-485/422 絶縁保護 RXバイオスとライン ・ ターミネイタの選択 電源リセッ トすることなく簡単な設定 C の広範囲温度で動作 -40~70 JetCon 2201-w / JetCon 2201-iw Industrial RS-232 to RS-422/485 serial converter パッケージ ・ チェ ック リスト Quick Installation Guide JetCOn2201シリーズには下記の品目 v 1.0 www.korenix.com V1.0 V1.0...
- Seite 39 All manuals and user guides at all-guides.com システムのインストール ユニッ トのマウン ト - DINレール DINレールマウント ： 4つのねじを締め付けて、 DINレールマウントキッ トを取り付け、 JetCon2201をDINレールにマウントしてください。 トラックからクリップを緩めるため、 クリップの底にマイナスドライバを 差し込んでください。 ユニッ トのマウン ト DIP Switch RS-232 2201i 3.5mm RS-232 to RS-422/485 Converter Wall Mount Screw 7.00mm RS-422/485-4w RS-485-2w 12-48V 壁にロックするためにねじを締めた後にユニッ...
- Seite 40 All manuals and user guides at all-guides.com DIP Switch RS-232 2201i RS-232 to RS-422/485 Converter Output Voltage: DC 24V/1A AC Input Switching Power Supply UL Certified RS-422/485-4w RS-485-2w 12-48V Earth Ground Power Input Range DC 12V~48V シリアルインターフ ェースの接続 JetCon 2201はRS-232をRS-422、 RS-485の4線式と2線式への変換をサポートしてます。 この RS-232はメスのDB-9のコネクタで、...
- Seite 41 All manuals and user guides at all-guides.com 4.2 RS-422/485 設定 JetCon 2201-w/2201-i にはRS-422/485のモードを選択したり、 120Ωのライン抵抗を提供するた めの5ピンのDIPスイッチがあります。 そのDIPスイッチの設定は下記のテーブルのようになります。 RS-422やRS-485の接続をする前に、 DIPスイッチが正しいモードに設定されていることを確認く ださい。 Description RS-422 RS-485 4-wire RS-485 2-wire RX +/- Terminator (120Ω) RX+/- Biasing (150KΩ) RX+/- Biasing (1KΩ) 2 3 4 5 アイドルマルチドロップ RS-485のネッ トワークにおいて、 すべてのノードがリッスン （受け側） の...
- Seite 42 All manuals and user guides at all-guides.com RS-422 4-wire Peer to Peer Architecture: Point to Point Baud Rate: 300~921.6 Kbps Distance: 4000 feet RS-232 to RS-422 4-wire Point to Point DIP Switch RS-232 DIP Switch RS-232 2201i 2201i RS-232 to RS-422/485 Converter RS-232 to RS-422/485 Converter RS-422/485-4w RS-485-2w...
- Seite 43 All manuals and user guides at all-guides.com RS-485 2-wire multi-drop Architecture: Master-Slave Mode. Max. Distance: 4000 feet Baud Rate: 300~921.6 Kbps Max. Node: 32 nodes RS-232 to RS-485 2-wire Multi-Drop DIP Switch RS-232 DIP Switch RS-232 DIP Switch RS-232 2201i 2201i 2201i RS-232 to RS-422/485 Converter...
- Seite 44 All manuals and user guides at all-guides.com 3DWHQW 1R 7DLZDQ *UDQWHG ,QYHQWLRQ , *UDQWHG ,QYHQWLRQ , *UDQWHG ,QYHQWLRQ , *UDQWHG ,QYHQWLRQ , *UDQWHG ,QYHQWLRQ , *UDQWHG ,QYHQWLRQ , *UDQWHG ,QYHQWLRQ , 8WLOLW\ 0RGHO 0 8WLOLW\ 0RGHO 0 7HO ...
