4.

ELECTRICAL CONNECTIONS

GB
The electrical connections and the start-up of the gearmotor
ARCB are shown in the installation manual of the E2 control
panel. To reverse the direction of rotation, exchange the motor
phases.
The electrical connections and the start-up of the gearmotor
ARC1BH are shown in the installation manual of the VIVAH
control panel. To reverse the direction of rotation, exchange
the motor phases.
The electrical connections and the start-up of the gearmotor
ARCBH are shown in the installation manual of the E2H control
panel. To reverse the direction of rotation, exchange the motor
phases.
All right reserved
All data and specifications have been drawn up and checked with the greatest care. The manufacturer cannot however take any
responsibility for eventual errors, ommisions or incomplete data due to technical or illustrative purposes.
ARC - IP1725
All manuals and user guides at all-guides.com
5. MAINTENANCE PROGRAM (every 6 months)
Without 230 V~ power supply and batteries if present:
-
-
-
-
-
Reconnect the 230 V~ power supply and batteries if present:
-
-
-
ATTENTION: For spare parts, see the spares price list.
10
Lubricate the levers of the gearmotor.
Lubricate the rotation pivot of the gate leaf.
Lubricate the gate leaf hinges.
Check the good conditions of the electric connection.
Check that the fixing screws of the gearmotor are firmly
tightened.
Check the power adjustment.
Check the good operation of all command and safety
functions (photocells).
Check the good operation of the release system.
