REDM10E
Ø 30mm
Ø 1" 3/16
Dimensioni d'ingombro e quote di fissaggio
Overall dimensions and fixing points
Dimensions d'encombrement et fixations
Maßen und Befestigungshöhe
112,5mm
4" 27/64
610mm
24" 1/64
Ø120mm
Ø4" 23/32
-3-
97mm
Ø60mm
3" 13/16
Ø 2" 23/64
800mm
31" 1/2
290mm
11" 27/64
Ø25mm
Ø 63/64"
620mm
24" 13/32
14mm
35/64"
