Systeminstallation - EcoFlow PowerOcean DC Fit Installationsanleitung

System
Installation
Installing
Battery Base
·Without adjustable feet
1
C1
65-85 mm
3
2
3 4
6
5
8
7
·With adjustable feet
1
C1
65-85 mm
• When drilling screw holes, avoid the water pipes and power cables buried in the
DANGER
wall and under the floor.
• When moving heavy equipment, assign enough personnel (two or more).
CAUTION
• When moving the battery pack, hold the handles on top of it.
NOTICE • Install the provided adjustable feet to level the battery base if the surface is tilted or
uneven.
C1
×4
C2
C2
C1
2
4
×2
C3
*Optional step
C3
8
7
2
×1
C4
2
3 4
6
5
5.0 N·m
en
10mm
Or
2 1 | 22
