Package
Inspection
·ECOFLOW POWEROCEAN PV STORAGE CONVERTER
A1
×1
EcoFlow PowerOcean PV Storage Converter
A4 ×12
Solar connector pair
A7 ×4
Screws
(M5*12)
·ECOFLOW POWEROCEAN LFP BATTERY BOX
×1
B1
EcoFlow PowerOcean LFP Battery
·ECOFLOW POWEROCEAN LFP BATTERY BASE
×1
C1
Battery base
• Check if the deliverables are intact and complete. If any item is missing or damaged,
NOTICE
contact the supplier.
• Retain the original packaging and documentation for further needs.
A2 ×1
Smart meter
×1
A5
METER port connector
(RS485)
A8 ×1
OT terminal
×2
B2
Battery T-shaped /
L-shaped mounting piece
×4
C2
Adjustable feet
×2
A3
Solar connector spanner
A6 ×1
WAN port connector
×8
B3
Screws
(M5*12)
×2
C3
Expansion bolt
(M6*60)
(RJ45)
×2
A10
Expansion bolt
(M6*60)
×1
C4
Marking-off template
1 9 | 20
