Device Explanation - Conceptronic CNB120 Benutzerhandbuch

ENGLISH
The device explanation picture below describes all elements of the notebook adapter:
Nr Description
AC input:
A.
B. Power LED:
Off
On
C.
Voltage selector:
Tip connector:
D.
6

3. Device explanation

AC input connection to connect the power cable to the notebook
adapter.
Show the power state of the notebook adapter.
The notebook adapter is not powered.
The notebook adapter is powered and ready to use.
Selector to set the output voltage for your notebook adapter.
Connector for one of the notebook tips included with the notebook
adapter.
