QM7 and QS7 Instruction Manual
Output Connections:
Module/Option
J1 Option connector
Global Option.
PMbus J5 Option connector
J206 Option connector
DM module
DM module J202, J203, J204, J205
Power connectors
DH module J206 Option connector
DH module J202, J203, J204, J205
Power connectors
SB module J204 Option connector
SB module
Power connectors
SC module J204 Option connector
SC module
Power connectors
SA module
Power connectors
SA module J204 Option connector
Connector Housing
(Molex)
51110-1060
(Molex)
51110-1260
(Molex)
51110-1260
-
(Molex)
51110-1060
-
(Molex)
51110-1060
J202, J203 -
(Molex)
51110-1060
J202, J203 -
J202, J203 -
(Molex)
51110-1060
Crimp pin Output
screw size
and torque
(Molex)
50394-8051
(Molex)
50394-8051
(Molex)
50394-8051
-
0.5 – 0.6Nm
(Molex)
50394-8051
-
0.5 – 0.6Nm
(Molex)
50394-8051
-
2.4 -2.6Nm
(Molex)
50394-8051
-
2.4 -2.6Nm
-
2.4 -2.6Nm
(Molex)
50394-8051
Page 30 of 40
Fast-on terminals
- -
- -
- -
M3 Four 6.35mm
fast-ons. Each rated
18 Amps
- -
M3 Four 6.35mm
fast-ons. Each rated
18 Amps
- -
M5 Four 9.5mm fast-ons.
Each rated 32 Amps
- -
M5 Four 9.5mm fast-ons.
Each rated 32Amps
M5 Four 9.5mm fast-ons.
Each rated 32Amps
- -
260297-10, Nov 2021
