Lofrans LEOPARD Installations-, Bedienungs- Und Wartungsanleitung Seite 19

Item Description
203 Seal - 35x45x7
209 Key - 6x6x30
226 Washer for screw M8
227 Nut - M8
253 Bearing - 6006
260 Spring washer for screw M8
272 Handle
273 Clutch nut
309 Bearing - 6203
311 Thrust bearing - 51105
312 Circlip - 43 Din 472
Hd cap special screw M10x16
331
334 O Ring seal - 2031
350 Round key 4x6,5
Hd cap screw M6x20
351
369 Washer for screw M10
386 Spring washer for screw M10
410 Seal - 30x42x7
417 Hex hd screw M8x30
418a Electric motor 1200W 12V
418b Electric motor 1200W 24V
418c Electric motor 1500W 12V
418d Electric motor 1500W 24V
420 Hex hd screw M10x25
450 Key - 8x7x80
Pawl
470
Oil plug 1/4"
474
520b Drum
521 Cone clutch
522a Gipsy chain 8 Iso
Gipsy chain 5/16" HT
522b
Gipsy chain 10 Iso - 3/8 HT
522c
522d Gipsy chain 3/8 Din 766
Gipsy chain 3/8 BBB
522e
Gipsy chain 3/8 PC
522f
Gipsy chain 12 Iso
522g
523a Clutch cone - inner
523b Clutch cone - inner for gipsy type 522g
524 Seal - 30x55x10
525 Circlip - 55 Din 472
526 Circlip - 30 Din 471
527 Key - 6x6x105
528 Main shaft
529 Main shaft
530 Gipsy cap
531 Cone clutch - outer
531a Cone clutch - outer for gipsy type 522g
532 Base
533a Stud M8x110
534 Gearcase - upper
535 O Ring seal - 4500
536 Seal - 45x60x7
537 Bearing - 16009
538 Circlip - 100 Din 472
539 Key - 8x7x35
540 Sleeve
541 Spring
542 Dog clutch
543 Wormwheel
544 Gearcase - lower
545 Worm
546 Seal - 25x45x10
547 Stripper
639 Washer for screw M8
LEOPARD
Kit Q.ty Item
Kit A 1 KA06101
Kit C 1 KB06101
Kit B 3 KC06101
Kit B 4 KD06101
1
Kit B 3
1
1
1
1
Kit D 1
1
Kit B
Kit A 1
Kit C 1
5
Kit B
Kit B 3
Kit B 2
Kit A 1
Kit B 3
1
1
1
1
Kit B 2
Kit C 1
1
1
1
1
1
1
1
1
1
1
1
1
1
Kit A 1
Kit D 1
Kit D 2
Kit C 1
1
1
1
1
1
1
4
1
Kit A 1
Kit A 2
2
Kit D 1
Kit C 2
1
1
1
1
1
1
Kit A 1
1
Kit B 4
Description
Kit A - Seals
Kit B - Screw&Nuts
Kit C - Keys
Kit D - Circlips
B.06.101 - Date: 11-2004
Kit Q.ty
1
1
1
1
