Digital Satellite Receiver
11. Technical Specification
Tuner & Channel
Input Connector :
Frequency Range :
Input Impedance :
Signal Level :
IF Frequency :
IF Band width :
LNB Power & Polarisation:
Current :
22 KHz Tone :
Amplitude :
DiSEqC Control :
Demodulation :
Input Symbol Rate :
FEC Decoder :
MPEG Transport Stream A/V Decoding
Transport Stream :
Profile Level :
Input Rate :
Video Resolution :
Audio Decoding :
Audio Mode :
Sampling :
Memory
Main Processor :
Flash Memory :
Program DRAM :
A/V & Data In/Out
TV SCART :
VCR SCART :
Audio Output
AUDIO R/L :
RS232C :
Power supply
Power Consumption :
Type :
Power Consumption :
Standby Power:
Physical Spezifikation
Size (B x H x T) :
Weight (Netto) :
Operating temperature :
Storage temperature :
Storage humidity range :
_______________________________________________________
F-type, IEC 169-24, Female
950 MHz to 2150 MHz
75....unbalanced
-25 to -65dBm
480 MHz
36 MHz
Vertical : +13.5V/Horizontal : +18V
400mA Max Overload Protection
Frequency : 22 ± 4KHz
0.6 ± 0.2V
Version 1.0/1.2 Compatible
QPSK
4 - 45 Ms/s
Convolutional Code Rate 1/2, 2/3, 3/4, 5/6 and 7/8
MPEG-2 ISO/IEC 13818 Transport stream Specification
MPEG-2 MP@ML
60 Mbit/s Max
720 x 576
MPEG/MusiCam Layer I & II
Single channel / Dual channel Joint stereo / Stereo
32, 44.1 and 48KHz
32 bit RISC CPU mit 54 MHz und 32 MBit SDRAM
8 Mbyte (Asynchronous)
4 Mbyte
Video Output(CVBS, RGB, S-VHS) Audio Output
Video Output (CVBS): Video Input(CVBS, RGB, S-VHS)
Cinch volume and Mute Control
Transfer rate 9 pin D-sub Type
90 to 250V AC, 50/60 Hz
SMPS
Max. 10W witout LNB
Verbrauch : 5W
340 x 60 x 230 mm
ca. 2.6 Kg
0°C to +45°C
-10°C to +70°C
5% ~ 95% RH (Non-Condensing)
Page 33
