Changing the saw blade

Combined cuts

The mitre angle and the vertical angle must both be set for combined mitre cuts. This
process is used, for example, to make picture frames, for cutting strips and for making
crates with angled side walls and also for roof trusses. Always test the cut first using a
piece of waste wood before you cut the actual material.
Changing the saw blade
WARNING!
Risk of injury: Improper handling may result in severe injury.
• Wear suitable protective gloves when changing the saw blade.
Notice!
Risk of damage: Using unsuitable saw blades may result in damage.
• Only use saw blades, which correspond to the characteristics (size, thickness,
permissible speed) specified in this user manual.
• Do not use any HSS saw blades and cutting discs.
• Make sure that any required spacer discs and spindle rings are suitable for the
spindle and the saw blade used.

Removing the saw blade

1. Pull the mains plug out of the socket.
2. Move the saw head to its highest position (see chapter "Use as a mitre saw").
3. Use your right hand to push the spindle lock
4. Use the hex key to loosen the saw blade screw
5. Push the release lever for the saw blade cover
13
cover up a few centimetres until you can pull the saw blade

Mounting the saw blade

Refer to the following schematic drawing when mounting the saw blade.
62
service@matrix-direct.net
All manuals and user guides at all-guides.com
29
.
16
.
37
and push the bottom saw blade
17
down and out.
