Sichern der Cassette
— die Sicherheitssperre 1 für Seite 1
— die Sicherheitssperre 2 für Seite 2 } & Abb. 1, Seite 20,
Danach
kann die Aufnahmetaste
@ Rec
19 nicht mehr betátigt
werden. Wenn Sie spater eine Cassette, deren Sicherheitssperren
entfernt worden sind, aufnehmen wollen, so brauchen Sie nur die
beiden kleinen Öffnungen mit einem Klebstreifen zu verschließen.
Pflege und Wartung
Um die ausgezeichneten technischen Qualitáten Ihres Cassettenre-
corders zu erhalten, ist es notwendig, von Zeit zu Zeit zu prüfen, ob
sich Staub oder Bandschichtreste an den Magnetkópfen, an der
dergabe bemerkbar:
— Taste Eject 2 drücken, das Cassettenfach 3 öffnet sich.
— Die Cassette entnehmen.
nutzen
ENGLISH
Power On/Off.
Eject Cassette-holder flap opening.
Cassette-holder flap.
Memory stops the tape at counter reading "000" during
fast forward and rapid reverse winding
Reset Tape counter reset button.
Dolby NR noise reduction circuits on/off button.
Indicator lamp indicating that the Dolby B NR noise
reduction circuit is on.
Indicator lamp indicating that the Dolby C NR noise
reduction circuit is on
9 Chromium dioxide tape selection indicator (CrO;).
10 Metal Tape selection indicator (METAL).
11 LH channel recording level indicator lamps.
12 RH channel recording level indicator lamps.
13 RH channel recording level adjustment control.
14 LH channel recording level adjustment control.
15 RH channel microphone connection jack.
16 LH channel microphone connection jack.
17 Metal tape selector.
18 @@ Mute Silent recording (for Music finder).
19 @ Rec Record.
20 Wi Pause.
21 Chromium dioxide tape selector.
22 Ferrous oxide tape selection indicator (NORM).
23 Ferrous oxide tape selector.
24 Mb FF Fast forward.
25 Selecting button for Dolby NR.
Dolby B NR = release button
Dolby C NR = press button to lock it
26 » Play Playback.
œ Noa Foz
27 44 Rew Rewind
28 N Stop Tape stop.
29 Phones Headphone jack.
30 Cinch sockets for connection of an amplifier (recording).
31 Cinch sockets for connection of an amplifier (playback).
Connecting cassette deck
— to amplifier
Using the two leads supplied as accessories, connect the amplifier
to the Cinch sockets: 30 for recording and 31 for playback.
- to the mains
Connect the machine to a 230 V ~ 50 Hz AC mains supply.
N. B.: The set carries voltage even stopped. It is necessary to unplug it
from the mains outlet to cut power off.
On/Off
Button Power 1.
Tape type selection
Your unit has been designed to ensure optimal recording and playback
with various types of cassettes. The cassettes which you purchase wil
be labelled accordingly.
Select the type of tape being used by pressing button:
— 17 Metal = for metal cassettes (pure ferrous tape, 70 us),
the corresponding 10indicator lights up.
— 21 Chrome = for chromium dioxide cassettes (70 us),
the corresponding 9 indicator lights up.
= for standard cassettes (120 us), the corresponding
22 indicator lights up.
- 23 Norm
