R/W S231
IMPORTANT NOTES
«ERROR_1»: message returned when a user inserts an unauthorised value for the S200 register (in the light of
current regulations).
«WARNING_1»: message returned when a user inserts an authorised value for the S200 register, but the
content of the S231 register is not compatible with the maximum power permitted for the channel selected. As
a consequence, the S231 register is automatically updated with the maximum permitted value for the channel
selected.
«WARNING_2»: message returned when a user inserts a value that is available but not authorised for the S231
register (in the light of the maximum permitted power for the channel selected). As a consequence, the S231
register is automatically updated with the maximum permitted value for the channel selected.
Users must use the «AT&W» command if they wish to save the update.
«WARNING_3» : cf note 6
Type Register
Serial link
R/W S210
R/W S211
R/W S212
R/W S213
R/W S214
R/W S215
R/W S216
208210A_UG_V1.6_ARFx3-PRO
All manuals and user guides at all-guides.com
RF exit level Adjusts the RF exit level
0
1
2
3
Function Description
Transmission rate Transmission rate of the serial link
in bits/s
«0»: 600
«1»: 1200
«2»: 2400
«3»: 4800
«4»: 9600
«5»: 19200
«6»: 38400
«7»: 57600
Data length «7»: 7 bits
«8»: 8 bits
Parity «1»: none
«2»: even
«3»: odd
Stop bits «1»: 1 stop bit
«2»: 2 stop bits
Timeout command Length of timeout for detecting ***,
in ms from 3 to 240
Type of interface «0»: RS232 only
«1»: RS232 or RS485 (DE/RE
lines managed)
Handshake «0» : hardware, RTS (limited to the
addressed protocol)
«2»: none
53-PRO 43-PRO 33-PRO
14dBm 10dBm 10dBm
20dBm 14dBm
24dBm 17dBm
27dBm
27/24dBm for the
ARF53-Pro
(note: USB versions are
set to 24dBm in order
to limit the current to
450mA)
17bBm for the
ARF43-PRO
Default value Note
4 1.2 & 5
8 5
1 5
1 5
3 1
1
