OWNER'S MANUAL -English
Programming software (downloadable from the site)
Thanks to the programming software it is possible to enhance the
performance of your radio or minimize functionality by deactivating
some predefined functions (CTCSS, TOT ...).
Functionality:
Programming buttons PF1 and PF2
Up to 30 custom channels
For more information, consult the instruction manual on the manu-
facturer's website. Any attempt to change the frequency or power of
the device invalidates the approval.
Functions
Power on / off and volume adjustment
Turn the Knob Knob to turn on the radio.
After turning on the device, you can adjust the volume
simply by turning left and right by adjusting Volume + or Volume -.
To turn off the radio, turn counterclockwise until you hear a click.
Communications
In order to communicate, all radios in the group must be
set to the same channel and sub code (CTCSS / DCS).
1. Hold the radio 5-8cm away from your mouth.
2. Press and hold the PTT button while speaking. The status LED will
light up green
3. Release the PTT button. You can now receive incoming calls. During
reception, the led will be red.
Channel selection
In standby mode, directly press PF1 key + / PF2 key - to scroll forward
or backward to select channel.
When the voice request function is activated, the corresponding
channel is transmitted with voice.
Programmable buttons
Buttons PF1 and PF2 are fully programmable and can assume differ-
ent functions according to your needs.
By default they are set:
PF1 = Button vox
PF2 = LED Light Button
The functions they can take on are the following:
1 Off (No function)
2 Monitor (Monitor function if held down opens the squelch)
3 Lamp (Press for 2 seconds to activate / deactivate Led light)
4 Warn (Press for 2 seconds to activate / deactivate alarm)
5 Vox (Press 2 seconds to activate / deactivate Vox)
6 Vox Delay (Press for 2 seconds to activate / deactivate Vox See
previous paragraph)
7 Key Lock (Press for 2 seconds to activate / deactivate key lock)
8 Scan (Press 2 seconds to activate / deactivate Channel Scan)
6
