Inflatable Products – Aquaglide makes some of the highest quality inflatable products in the world. With
proper care and maintenance, our products are expected to last for years under normal use. We list important
tips and instructions below. If unsure about any point, please reach us through our website at Aquaglide.
com/contact-us.
Note: see Anchoring instructions (below) before inflating this item. Strong winds can make it difficult to control
this product. Be aware of weather conditions before installation.
Air Pump - Use an air pump recommended for inflating your product. For products this size, use of a high-
volume electrical pump is best. Air pressure requirements are low – 5.0psi (0,35bar) or less. Air compressors
designed for high-pressure inflation are not recommended because they can easily lead to over-inflation.
Valve(s) – This product uses Halkey Roberts – type (HR) valves. Valve attaches to product using a threaded
backing plate, making it easily replaceable in the unlikely event of damage.
Access valve using a coin or flat tool to twist the tamper-resistant cap counter-
clockwise. To close, insert the cap and twist clockwise using the same tool.
Note: cap is the secondary air seal. See A.
To inflate, an air pump with Halkey Roberts – type (HR) valve fitting is required.
Insert fitting into valve and twist clockwise to lock in place. See B.
Valve Operation: To operate Halkey Roberts – type (HR)
valve, press plunger and turn 90 degrees to set valve for
inflate and product use (plunger out = 1-way airflow). Press
plunger and turn 90 degrees to deflate (plunger in = 2-way
airflow). Note: valve is primary air seal. After inflation, close
with cap for secondary seal. See C.
Pressure Release Valve: Product is fitted with a pressure
release valve (PRV) in critical chamber(s) to help provide
catastrophic protection against damage caused by
over-inflation. It is still necessary to check and regulate air
pressure to maintain proper working pressure levels. PRV
has a unique setting specified to release above, and to close
near working pressure. PRV attaches to product using a
threaded backing plate, making it easily serviceable. See D.
TRiB Solar-powered Gauge: Product is fitted with a TRiB CG solar-powered
air pressure gauge (manometer) in critical chamber(s). TRiB CG contains no
batteries and uses patented technology to provide continual readings of air
pressure in the chamber.
No special maintenance is required for TRiB CG. Clean with soap and water -
avoid solvents which may damage the device. If gauge is not functioning properly, contact Aquaglide.
TRiB CG attaches to product using a threaded backing plate. Gauge can be removed and replaced by hand,
but a specific gauge tool may be preferable. Contact Aquaglide for the required tool.
TRiB CG can display units in PSI, kPa or Bar. Setting a new unit preference must be done in a well-lit
environment (i.e. sunlight). If light is not sufficient the display may read "SUN". In this case, simply move the
gauge to increase light exposure and complete the process. To change units, follow the steps below:
1. With chamber deflated, carefully hold TRiB CG backing plate in place and unscrew gauge in a counter-
clockwise direction until free.
2. Once removed from chamber, locate "SET" button on the back side of gauge. Align a fine tool (~1mm
6
ASSEMBLY
A
B
C
Inflate (1-way)
D
www.aquaglide.com
Deflate (2-way)
