5.3 Operation Guidelines

NO. Item
Power ON
1
Power ON
2 Power OFF
3 Pairing
SBV as ouput
4
power(EPS ready)
SBV standby
5
mode
6 Charing for SBV
7 Charing for SBV
Grid+SuperBaseV
8 automatically
switches work
Only Grid works (
9
bypass mode)
Turns off all
10
outputs

5.4 Connect with SuperBase V6400/4600

Zendure's Home Panel with EV Outlets is a smart load side transfer switch. It's
also a fast-charging dock for SuperBase V and features two EV outlets. A Home
Panel can be connected to one or two SuperBase V units' ZenT2 Port.
Press the AC Power Button for 3 seconds to connect with Home Panel. Refer to
the latest Zendure App for more information.
4
Action
Press Power / Pause
Button for 3 seconds
Briefly press Power /
Pause Button
Briefly press Power /
Pause Button
Press and hold IoT
Reset Buttom for 3
seconds
Pairing completed
Pairing timeout(3
minutes)
Briefly press ZenX
Port Buttom
Briefly press ZenX
Port Buttom
Press and hold ZenX
Port Buttom for 3
seconds
Press and hold ZenX
Port Buttom for 10
seconds
Transfer switch
pointing to "II"
Transfer switch
pointing to "I"
Transfer switch
pointing to "O"
Indicator
Power indicator on
EV outlet green
indicator on
Power indicator on
EV outlet green
indicator on
Power indicator off
IoT Indicator flashes
IoT Indicator on
IoT Indicator flashes
ZenX Green indicator
on
ZenX White
indicator flashes
ZenX White
indicator on
ZenX White
indicator on
Grid indicator on
Grid indicator on
Only Grid indicator
on
Remark
First time use
only
Only when SBV
no power
The factory
default mode
