DIP explanation
VLAN Port Isolation
Default Standard Switch
Extend Link Extension
LED and Interface Explanation
PWR Power supply
indicator Red
SW RJ-45 LINK
Indicator Green
Link ACT RJ-45 ACT
indicator Green
Downlink designated ports are isolated from each
other, only transmit data with the uplink port.
All ports communicate freely.
The specified port speed drops to 10 Mbps/s, max PoE
transmission is 250 meters.
Lighting Powered
Un-Light No power
OFF Normal
Vlan Lighting
Extend Slow flash
Lighting Connecting
Flashing
Data Transmit
Un-Light
Disconnect
