Hardware connection

Power Socket
Power input:
AC100-240V
Specifications
Network Protocol:
PoE Standard:
Max each port:
Max each port:
PoE Compatibility:
PoE port output:
Power pin:
Network Media:
Optical:
Performance Specification:
Power Supply
Product Dimension
Package Dimension
Internet
IEEE802.3/IEEE802.3u/IEEE802.3x
IEEE802.3ab/IEEE802.3z
IEEE802.3af/IEEE802.3at
15.4 W (IEEE 802.3af)
30 W (IEEE 802.3at)
IEEE 802.3af/ at adaptive
DC48-55 V
Power over spare pairs 1/2 (+), 3/6 (-)
10BASE-T: Cat 6 UTP (≤250 meter)
100BASE-TX: Cat5 or more UTP (≤100 meter)
1000BASE-TX: Cat5 or more UTP (≤100 meter)
MultiMode Fiber: 850 nm, 1310 nm,
Transmission Distance: 550/2 Km
Single-Mode Fiber: 1310 nm, 1550 nm,
Transmission Distance: 20/40/60/80/100/120 km
Bandwidth: 10.8 Gbps
MAC: 2 K
Packet Buffer Memory: 1 M
Packet Forwarding Rate: 8 Mpps
Power input: AC100-240 V 50/60 Hz
Output: 52 V 5.76 A, Power Budget: 300 W
320 mm * 210 mm * 46 mm
370 mm * 275 mm * 85 mm
4
Powered Device (PD)
Router
NVR
SFP Slot
Monitor
