Product Assembly

Part Name
On/off button
Mode button
Handheld release
button
On/off button
Mode button
Dirt cup release button
Dirt cup
Dirt cup bottom
release button
brushroll
Handle push button
Handle assembly
Handheld Vacuum
Handle release button
Lower body
Rear wheel
Brushroll cover latch
Rear wheel
