English
Application
Siedle Compact audio door station,
for installation in the In-Home bus
or as a replacement device in the
Siedle Basic audio set. With the
functions calling, speech and door
release.
Performance features:
• Integrated door loudspeaker
• Adjustable voice volume
• Number of integrated call buttons:
1, 2, 4
• Acoustic button acknowledgement
can be activated
• Backlit nameplates exchangeable
from the front
• Backlit info sign for house number,
logos, opening times, etc.
• For surface mounting with housing
front made of high-quality plastic
Electrical voltage
Mounting, installation and servicing
work on electrical devices may only
be performed by a suitably qualified
electrician.
Electrostatic charging
As a result of electrostatic charging,
direct contact with the circuit board
can result in destruction of the
device. Direct contact with the circuit
board must therefore be avoided.
Scope of supply
• CA 850-...
• Siedle screwdriver
• This product information
Mounting
1 Unscrew the front of the housing.
To do this, release the Siedle screw
on the underneath of the housing.
Hinge the front of the housing
forward.
6
All manuals and user guides at all-guides.com
2 Surface mounting the door sta-
tion. Recommended mounting
height appr. 1.50 m /4.9 ft. to centre
device. Please note: The cable is
inserted in the lower area of the
base plate!
3 Strip back the installation cable
close to the wall (appr. 10 mm) and
insert the cores into the base plate.
Fasten the base plate using 4 screws.
Close the two openings at the top
using rubber stoppers.
4 Install in accordance with the
wiring diagram. The cores may only
be laid in the admissible installation
space.
Important!
Before using the door release
terminal(s) (door release relay con-
tact), observe the "Door release
actuation" information in the
System Manual In-Home bus: Audio
or Video.
Terminal assignment
Ta, Tb In-Home bus (Audio)
Tö, Tö Relay contact door release
5 Depending on the installation
environment, it may be necessary
to change the door station speech
volume in order to permit clear
speech transmission.
6 Hook the front of the housing
onto the base plate at the top and
close. Tighten the screw on the
underneath of the housing.
Lettering
7 Open the nameplate from the
outside, for example using a flat
bladed screwdriver, and carefully
remove the inscription insert. To
insert the nameplate, lock into place
by exerting light pressure.
8 Info sign from the inside, e.g.
open using flat blade screwdriver
and remove inscription field. To
insert, clip in the info sign exerting a
slight pressure.
Exchanging the door station /
Dismantling
1 Unscrew the front of the housing.
To do this, release the Siedle screw
on the underneath of the housing.
Hinge the front of the housing
forward.
9 Release the connections, remove
the rubber plugs in the two upper
openings, unscrew the base plate
of the circuit board and exchange.
Assembly takes place in reverse
sequence. (1:1 exchange)
Commissioning and
programming
10 Programming button for the
Siedle Compact door station.
Door station programming mode
(manual programming): At the door
station, hold down the program-
ming button for 4 seconds. A pro-
tracted acknowledgement tone is
then audible which is repeated every
5 seconds as long as the program-
ming mode remains active.
The following information products
are to be observed for commis-
sioning and programming:
• System Manual In-Home
bus: Audio or Video (when used as a
door station in the In-Home bus)
• Product information
SET CAB 850-... (when used
as a replacement device in the
Siedle Basic audio set)
Specifications
Contact type: contact 24 V, 2 A
Protection system: IP 54
Ambient temperature:
–20 °C to +55 °C
Dimensions (mm) W x H x D:
82 x 226 x 33
