FIXING LIMIT DEVICE

Fig. 9
The gate must feature check stops for aperture and closure that prevent the gate from derailing.
The position of the limit device must ensure that the limit devices do not collide with the pinion.
Manually open the gate leaving, based on the weight of the gate, a space between 30 a 50 mm.
between the gate and the mechanical stop.
Fix the limit device using the pins (fig. 10) leaving a space between the magnetic limit device and
the
reduction gear of max 10 mm(fig. 9) repeat the operation with the gate closed.
Fig. 10
