Model
Article number
Material
Case size (L x W x H), (mm)
Net weight (kg)
Main board size
5�25" bays
3�5" bays
2�5" bays
Front I/O ports
Front cooling fan
Rear cooling fan
Optional cooling
PCI slots
Power supply
CPU cooler height (mm)
Graphics card length (mm)
Liquid cooling system
7.

INSTALLATION PROCESS

Before commencing assembly please ensure that all accessories and components are available and in the
amount listed�

7.1 Accessories Pack

Images Part Name
#6-32 Round head screws
M3 HDD screws
Silent Base 600 Orange / Black / Sliver / Red / Green
BG005 (Orange), BG006 (Black), BG007 (Silver), BG008 (Red), BG009 (Green)
0�7mm SECC, ABS, nylon
495 x 230 x 493
7�8
Mini-ITX, Micro-ATX, ATX
3
3
3
USB 3�0 (2 of), USB 2�0 (2 of), HD Audio (Microphone and Headset)
140mm @900rpm - be quiet! Pure Wings 2
120mm @1200rpm - be quiet! Pure Wings 2
2x 140/120mm (top), 1x 140/120mm (bottom), 1x 140mm (front),
1x 120mm (side panel)
7
PS2 ATX, maximum length 300mm
170 max�
290 (with HDD cage), 400 (HDD cage removed)
Front 120/140mm radiator (optional)
Rear 120mm radiator (optional)
Top 240mm radiator (optional)
Amount Usage
8 Secure motherboard
12 Secure rubber rail to HDD
5
