• Use of accessories and extensions – Depending on the

accessory or extension ﬁ tment can reduce the fastening force of

the impact wrench.

• Bolt/Nut – Fastening torques may diﬀ er according to the

diameter of the nut or bolt, the class of nut/bolt and the length of

nut/bolt.

• Condition of the fastener – Contaminated, corroded, dry or

lubricated fasteners may vary the fastening torques.

• Condition and base material – The base material of the fastener

and any component in between the surfaces may eﬀ ect the

fastening torque (Dry or lubricated base, soft or hard base, disc,

seal or washer between fastener and base material).

IMPACTING TECHNIQUES

The longer a bolt, screw, or nut is impacted, the tighter it will

become.

To help prevent damaging the fasteners or workpieces, avoid

excessive impacting.

Be particularly careful when impacting smaller fasteners because

they require less impacting to reach optimum torque.

Practice with various fasteners, noting the length of time required

to reach the desired torque.

Check the tightness with a hand-torque wrench.

If the fasteners are too tight, reduce the impacting time.

If they are not tight enough, increase the impacting time.

Oil, dirt, rust or other matter on the threads or under the head of

the fastener aﬀ ects the degree of tightness.

The torque required to loosen a fastener averages 75% to 80% of

the tightening torque, depending on the condition of the contacting

surfaces.

On light gasket jobs, run each fastener down to a relatively light

torque and use a hand torque wrench for ﬁ nal tightening.

BATTERIES

Battery packs which have not been used for some time should be

recharged before use.

Temperatures in excess of 50°C (122°F) reduce the performance

of the battery pack. Avoid extended exposure to heat or sunshine

(risk of overheating).

The contacts of chargers and battery packs must be kept clean.

For an optimum life-time, after use, the battery packs have to be

fully charged.

To obtain the longest possible battery life remove the battery pack

from the charger once it is fully charged.

For battery pack storage longer than 30 days:

Store the battery pack where the temperature is below 27°C and

away from moisture

Store the battery packs in a 30% - 50% charged condition

Every six months of storage, charge the pack as normal.

BATTERY PACK PROTECTION

In extremely high torque, binding, stalling and short circuit

situations that cause high current draw, the tool will vibrate for

about 2 seconds and then the tool will turn OFF.

To reset, release the trigger.

Under extreme circumstances, the internal temperatur of the

battery could become to high. If this happens, the battery will shut

down.

Place the battery on the charger to charge and reset it.

TRANSPORTING LITHIUM BATTERIES

Lithium-ion batteries are subject to the Dangerous Goods

Legislation requirements.

Transportation of those batteries has to be done in accordance

with local, national and international provisions and regulations.

ENGLISH

• The user can transport the batteries by road without further

requirements.

• Commercial transport of Lithium-Ion batteries by third parties is

subject to Dangerous Goods regulations. Transport preparation

and transport are exclusively to be carried out by appropriately

trained persons and the process has to be accompanied by

corresponding experts.

When transporting batteries:

• Ensure that battery contact terminals are protected and insulated

to prevent short circuit.

• Ensure that battery pack is secured against movement within

packaging.

• Do not transport batteries that are cracked or leak.

Check with forwarding company for further advice

MAINTENANCE

Use only Milwaukee accessories and spare parts. Should

components need to be replaced which have not been described,

please contact one of our Milwaukee service agents (see our list of

guarantee/service addresses).

If needed, an exploded view of the tool can be ordered. Please

state the machine type printed as well as the six-digit No. on the

label and order the drawing at your local service agents or directly

at: Techtronic Industries GmbH, Max-Eyth-Straße 10,

71364 Winnenden, Germany.

SYMBOLS

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work

on the machine.

Please read the instructions carefully before starting

the machine.

Do not dispose electric tools, batteries/rechargeable

batteries together with household waste material.

Electric tools and batteries that have reached the

end of their life must be collected separately and

returned to an environmentally compatible recycling

facility.

Check with your local authority or retailer for

recycling advice and collection point.

No-load speed

Impact range

Volts

Direct current

European Conformity Mark

British Confomity Mark

Ukraine Conformity Mark

EurAsian Conformity Mark.

TECHNISCHE DATEN

AKKU-SCHLAGSCHRAUBER

Produktionsnummer ........................................................................................

Leerlaufdrehzahl ...................................................................

Schlagzahl .............................................................................

Drehmoment .........................................................................

Maximale Schraubengröße / Mutterngröße ..........................
