Rear camera:
Before installation, choose the correct place for mounting. Mounting
place has to be installed in a way, that it does not obstruct field of view.
Rear camera can be installed in two ways:
• On mounting tape. Peel off first piece of paper from the tape and stick
it to the camera's mounting bracket. Peel off second piece of paper
from the tape and stick the camera do selected place.
• On screws. Drill the holes in selected place and screw in the camera.
During drilling make sure, that no damage is done to any wire,
especially for safety systems.
After connecting the 2,5 mm plug to the AV socket in the dashcam, the
view from rear camera will appear in the top left corner of the display
(press the down button to enlarge the image). If red wire will be
connected to the reversing lights (for example with quick connector),
after shifting into reverse gear, the view from rear camera will be
enlarged, helping the driver with maneuvering the vehicle. Note: for this
function to work, the red wire has to be connected to the same electrical
installation.
MicroSD card installation
1. Place the microSD card in the proper slot of the device and press
gently, until it clicks. Make sure, that the card is installed in correct
way.
2. To take out the card, press it gently. When the card slides out of the
slot, take it out.
Notes:
• The microSD card in the device will be treated as storage device. It is
advised to format it first.
• Use microSD cards with class 10 or higher, with maximum capacity of
32 GB.
EN
Turning on and off
1. To turn on the device:
• Press and hold the power button
• If the dashcam is connected to the cigarette lighter socket, the camera
will turn on automatically after ignition and start recording.
2. To turn off the device:
• Press and hold the power button
• If the camera is connected to the cigarette lighter socket, after turning
off the engine, the dashcam will turn off after 5 seconds.
12
Owner's manual Owner's manual
Navigating the menu
• Press the M button to change the mode. Press and hold the M button
to go to settings menu.
• Press the power button to turn on or off the display.
• Use the up and down buttons to navigate the menu.
• Press the OK button to confirm options.
Start recording
• If the microSD card is inserted and correctly formatted, the recording
will start automatically after providing the power to the dashcam (from
cigarette lighter socket or from USB port).
• To start or stop the recording press the OK button, while in recording
mode.
• In order for camera to turn on and start recording after shake, turn on
the Parking guard on (in the recording menu). Select the desired
sensitivity of the function in the G-sensor menu.
• To change the size of the preview from rear camera, press the up
button.
Taking pictures
• To take a picture, while in the photo mode, press the OK button.
Browsing files
• Use the up and down buttons to switch between files.
• To play the video file, press the OK button.
• To delete or lock the file, press the M button and select desired option.
Dashcam settings
• Resolution: change the resolution of recorded videos.
• Loop recording: change the duration of recorded videos.
• White balance: change the white balance settings.
• EV: change the brightness of recorded videos.
• Motion detection: record video automatically after detecting the
moving.
• Audio: record the voice.
• Parking mode: turn on the parking mode.
• Date tag: turn on the date stamp in recordings.
• G-sensor: turn on the gravity sensor and set its sensitivity.
• Beep sound: turn on the sound after pressing a button.
EN
