a cloth soaked in warm water and a degreasing agent, and then dry. Do not use agents which could
scratch the surface.
•
Set the cooker on a firm and stable floor in a room that is suitable for the cooker to operate in, com-
pliant with building regulations, and then level with adjustable feet (Fig. 4).
Conditions for connection to mains:
•
Make sure that the mains voltage corresponds to the voltage indicated on the rating plate of the ap-
pliance (Fig. 5 Pos. 3)
•
To connect the appliance to the mains, connect the power cord to the terminal box on the back of the
appliance (Fig. 5 Pos. 2). The power cord with plug is NOT part of the kit and must be purcha-
sed.
•
The device must be connected to an equipotential equalization system using the equipotential screw
(Fig. 5 Pos. 1) on the back of the device. It is marked with the following symbol:
Rear panel components:
1. Equipotential bolt
2. Terminal box
3. Rating plate
The power cord should be flexible, oil-resistant, earthed, polychloroprene-coated - it can be made by the
manufacturer and available from him or in specialist repair shops!
Figure 6. Connecting the unit to the mains.
•
Only an authorized technician with a certificate for electrical works may connect the device to the
Figure 4. Leveling the device
Figure 5. Rear view of unit
PE – protective wire (yellow-green)
N – neutral wire (blue)
L1, L2, L3 – phase wires (other colors)
