GB
Installation and Operating Instructions
Hand Dryer HD 701 AM
These installation and operating instructions should be read carefully and retained for future
reference.
Ensure that these installation and operating instructions are passed on to any new owner.
Description of Hand Dryer
The sole purpose of the hand dryer is to dry hands. The hands are dried in a stream of warm air
that flows out of the swivel nozzle. The hands can be rubbed together to accelerate drying.
The hand dryer is operated by a proximity switch which starts the unit automatically when hands
are placed under the air outlet nozzle. When the hands are removed from the airflow, the
proximity switch automatically stops the dryer after a run-on delay of approximately 2 seconds.
The hand dryer is designed to be mounted indoors only..
It must be mounted on a vertical wall with the air outlet opening pointing downwards.
The installation and electrical connection of the hand dryer may only be performed by a
competent electrician!
All safety measures taken must conform to the applicable national regulations effective in the
relevant country! The electrical supply circuit to the dryer must incorporate an all-pole isolating
switch with at least 3mm contact clearance on each pole!

Technical Specifications

Type
Operating voltage
Rated power
Protection type
Class of protection
Type of connection
Type of mounting
Operation
Time delay
Airflow rate
Noise level
Dimensions W x H x D
Weight
Specifications subject to change without notice
Materials supplied with hand dryer
The hand dryer comes complete with a drilling template, special spanner and mounting
hardware.
HD 701 AM
220-240 V~ 50/60 Hz
2250 Watt
IP 23
I, with earting conductor
Fixed wiring or flexible
cord
Wall mounting
Proximity switch
2 seconds
3
470 m /h
70 dB (2 m)
276 x 245 x 210 mm
4,7 kg
5
hd701-gb_ba 11/07/A
