3.

DESCRIPTION

The TS6500CIM Series Automatic Techkit Mixer provides complete automatic
mixing of two-component materials packaged in
supply.
Equipped with a universal power supply, the TS6500 mixer is immediately usable
anywhere in the world. The automatic fluid sensing device makes it very simple
for the operator to install and setup all cartridge kit sizes. The user friendly
firmware provides up to 10 programmable mixing sequences with storage for 10
profiles.
The TS6500CIM Series is available in five versions:
• TS6500CIM-6 for 2.5oz. (60ml), 6.0oz. (160ml) and 8.0oz. (220ml) Kit
• TS6500CIM-20 for 20oz. (550ml) Kit
• TS6500CIM-RS-6 for 6.0oz. (160ml) Kit with reduced motor speed (116 RPM)
• TS6500CIM-SMR-6 for 6.0oz. (160ml) Kit with steel mix rod
• TS6500CIM-SMR-20 for 20oz. (550ml) Kit with steel mix rod
The following conversion kits are also available for your conveniences:
• CK6500-6 Conversion kit for 2.5 (60ml), 6.0 (160ml) and 8.0 oz. (220ml) Kit
• CK6500-10 Conversion kit for 1/10 gal.(310ml) Kit
• CK6500-20 Conversion kit for 20 oz.(550ml) Kit
4.

SYMBOL DEFINITIONS

5.

EMERGENCY STOP

In case of an emergency, the mixing operation can be stopped at any time by
pressing the EMERGENCY STOP BUTTON, (Fig 2, 10). After the problems have
been fixed, the machine can be restarted by pulling and turning the emergency
button counter clockwise. The mix cycle will start from the beginning.
4
