15 Fluid Level Magnet
16 Plunger Assembly
Flow Control; Main
17
Cylinder
Flow Control;
18
Injection Rod
Voltage Select
19
Switch
Power Input Socket
20
with Fuse Box
21 Air Filter
22 Wrench
23 Accessories Bracket
Cartridge Holder
24
Bracket
• Works with fluid level sensor
• Locks cartridge in place
• Applies steady pressure to prevent air entrapment
• Controls the speed of the main cylinder
• Rotate the flow control screw clockwise to increase
the speed.
• Rotate the flow control screw counterclockwise to
decrease the speed
• Controls the speed of the injection rod
• Rotate the flow control screw clockwise to increase
the speed.
• Rotate the flow control screw counterclockwise to
decrease the speed
• Select 115V or 230V
• Input power connection
• Provides air filtration
• Used to install the air filter assembly and drive
spindle assembly
• To hold wrench or other accessories
• To hold extra cartridge holder
