Once the the Rugiada sensor has been activated the sensor element is ready to detect any
alarm conditions. Pressing the SET button, the unit will operate in "test" mode for the next
3 minutes, or in case of alarm, the awning will close or open and, once it has completed
that action, it will be possible to immediately trigger another alarm. It is even possible to
activate the sensor by simply placing your hand on top of the sensor element.
To delete the sensor from the motor, an already programmed remote control must be
used. The deleting sequence is the following:
+
A B
The Rugiada sensor needs no particular maintenance. However any dust or residue that
collects on its surface will limit its sensitivity. Therefore, it is suggested that it be cleaned
off once or twice a year with a damp cloth. Make sure to have disconnected the power
source prior to cleaning, otherwise contact with the sensor could engage the opening
and closing of the awning by triggering an alarm, possibly causing harm to the person
involved or others.
Symptom
Failure to open or
close the awning in
case of rain.
TESTS AND OPERATION
DELETING THE RUGIADA SENSOR
A
MAINTENANCE
WHAT TO DO IF....
Cause
Sensor has no power.
Presence of residue on the
sensor element.
*Note: the Rugiada sensor is compatible only with the indicated
motors and control units, manufactured beginning 01/2014.
Remedy
Check the power cable for the
sensor.
Clean the surface the sensor
element with a damp cloth after
disconnecting the power.
18
SET
2 sec
