INSTALLATION
SEAT & PEDAL ASSEMBLY
[a]
Attach the Seat Assembly
and secure with two Lock Washers (M8)
(M8xp1.25x16mm)
[41]
[b]
Thread the Right Pedal
the Main Frame
clockwise into the right crank. Tighten the Pedal as firmly
as possible.
[c]
Thread the Left Pedal
Frame
wise into the left crank. Tighten the Pedal as firmly as
possible.
[d]
Finish the assembly, make sure that all parts are tightened
before you use the equipment.
[3]
[29]
[39]
26
[3]
to the Main Frame
[29]
, two Bolts
[39]
and one Bolt (M8xp1.25x50mm)
.
[10]
into the right crank area of
[1]
. Firmly tighten the Right Pedal
[9]
into the left crank area of the Main
[1] [9]
. Firmly tighten the Left Pedal counter-clock-
[3]
[9]
[29]
[39]
[41]
INSTALLATION
Put your fingers into the holding hole located on the back of
[1]
the Seat and gently move the item to the desired location.
Make sure the floor is level while towing the item.
[10]
[10]
Hold here.
