START UP

Unpack the box in a clear area. Follow the List of Assembly Parts below
to check and make sure all assembly parts are present and in good
condition. Do not dispose of the packing material until the assembly
process is completed. Assembly tools and hardware kit have included
for you to use when assembling the product
Rear Support Frame
22
Seat Cushion Lower Seat Cover Assembly
Pedal Rear Decoration Cover
Main Frame Assembly
START UP
NOTE:
Please review below to know the content of the hardware kit Some
small parts may have been pre-attached for shipping. If a part is not in
the hardware bag, check to see if it has been pre-assembled.
Hardware Kit Part No. and Description
29 Lock Washer (M8)
33 Screw (M4x12mm)
39 Bolt (M8xp1.25x16mm)
40 Bolt (M8xp1.25x30mm)
41 Bolt (M8xp1.25x50mm)
THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY:
multi wrench tool w / phillips
screwdriver
Q'TY
2 pcs
4 pcs
2 pcs
2 pcs
1 pcs
allen wrench
(6 mm)
