Attaching the Base Plate to the
Mount
1. Thread the screws
washers , mount
➋
.
➍
➋
➊
2. Tighten the nuts
plate.
The recommended torque is 15 to 20
lbf-in. (1.7 to 2.25 Nm).
Assembling the Mount
1. Insert the ball of the handlebar base
into the double-socket arm
➊
4
through the
➊
, and base plate
➌
➌
➍
to secure the base
➎
.
➋
➊
➎
2. Insert the ball of the base plate
attached to the mount
other end of the double-socket arm.
3. Tighten the knob slightly.
4. Adjust for optimal viewing and
operation.
5. Tighten the knob to secure the mount.
➋
➌
with the
➌
