Wiring diagrams
Fronius Smart Meter 63 A / 1 PH
OUTPUT
INPUT
RS 485
Rx / Tx GND
-
+
N
33 34 35
L L
in
out
*
120 Ω
L
LOAD
N
Modbus transmission Modbus Übertragung
Transmission speed: Übertragungsgeschwindigkeit:
9600 baud
Address: 1 Adresse:
Parity bit: none Parity bit:
DE
Anschluss-Schemata
Fronius
Datamanager
- D+ D-
ON
* incluso con l'apparecchio
supplied with the device
joint á l'appareil
liegt dem Gerät bei
Transmissione Modbus
Velocità di trasmissione:
9600 baud
1 Indirizzo:
keines Bit di parità: nessuno
IT
Schemi d'inserzione Schemas de raccordement
Transmission Modbus
Vitesse de transmission :
9600 baud
1 Adresse :
Bit de parité:none
