Panasonic TX-28DK20D Serviceanleitung Seite 18

Cct Ref Parts Number
Q2102 BC857B
Q2103 BC857B
Q2301 BC847B
Q2302 BC857B
Q2303 BC847B
Q2304 BC857B
Q3006 BC847B
Q3007 BC847B
Q3201 BC847B
Q3202 BC847B
Q3203 BC857B
Q3204 BC857B
Q3205 BC847B
Q3206 BC847B
Q3207 BC847B
Q3208 BC847B
Q3209 BC847B
Q3352 BC857B
TRANSFORMERS
T501 ETH19Y193AY
T801 ETS42AE2G6AD
T802 ETP35KAN619U
COILS
J26 EXCELDR35V
J212 EXCELSA35V
L101 TLT100K991R
L102 TLT068K991R
L103 EXCELSA35B
L104 TLTACT4R7K
L105 TLTACTR47K
L106 TLTACT100K
L107 TLTACT6R8K
L114 ELJFC2R2KF
L115 ELJFC2R2KF
L301 TLTACT4R7K
L353 TLT150K991R
L363 TLT100K991R
L373 TLT150K991R
L381 TLT220K991R
L382 ELESN6R8KA
L451 EXCELSA35T
L501 EXCELSA35T
L581 ELHKLB040B
L582 ELC18B271E
L584 ELHKLB025B
L586 EXCELDR35C
L606 ELESN100KA
L701 ELC18B271E
L704 ELC10D332E
L705 EXCELDR35V
L850 EXCELSA35T
L851 EXCELSA35T
L852 ELEIE470KA
L855 EXCELSA35T
L856 EXCELSA39V
L910 EXCELSA35T
L911 EXCELSA35T
L912 EXCELSA35T
L1061 TLT331K991R
L1103 TLTACT100K
L1104 EXCELSA35T
L1105 ELJFC2R2KF
L1501 ELESN2R2KA
L1502 ELESN2R2KA
L1503 ELESN2R2KA
L1504 ELESN2R2KA
Description
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSISTOR
TRANSFORMER
TRANSFORMER
TRANSFORMER
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
Cct Ref Parts Number
L1505 ELESN100KA
L1506 ELESN100KA
L1507 ELESNR22KA
L1508 ELESNR22KA
L1509 ELESN100KA
L1510 ELESN100KA
L1514 ELESN100KA
L1515 ELESNR39KA
L1516 ELESN4R7KA
L1517 ELESN4R7KA
L1518 ELESN4R7KA
L1519 ELESNR39KA
L1520 ELESN2R2KA
L1521 ELESN1R0KA
L1522 ELESN2R2KA
L1523 ELESN2R2KA
L1524 ELESN2R2KA
L1525 ELESN100KA
L1526 ELESN100KA
L1527 ELESN100KA
L1528 ELESN100KA
L1529 ELESN100KA
L2101 TLTACT100K
L2103 EXCELSA35T
L2104 TLTACT4R7K
L3001 ELEMV1R5MA
L3002 ELEMV1R5MA
L3003 ELEMV1R5MA
L3004 ELEMV1R5MA
L3201 ELEBR6R8KA
L3202 ELEBR6R8KA
L3204 TLT331K991R
FILTERS
L804 ELF18N012A
L1901 ELF18N012A
X101 EFCT6504BF
X102 EFCT7004BF
CRYSTALS
X1101 TSSA121
X1501 4730007267
X1502 4730007341
X2101 4730007158
RESISTORS
C510 ERJ6GEY0R00
JA1 ERJ6GEY0R00
JA2 ERJ6GEY0R00
JA3 ERJ6GEY0R00
JA4 ERJ6GEY0R00
JA5 ERJ6GEY0R00
JA6 ERJ6GEY0R00
JA7 ERJ6GEY0R00
JA8 ERJ6GEY0R00
JA9 ERJ6GEY0R00
JA10 ERJ6GEY0R00
JA12 ERJ6GEY0R00
JA13 ERJ6GEY0R00
JA14 ERJ6GEY0R00
JA15 ERJ6GEY0R00
JA16 ERJ6GEY0R00
JA17 ERJ6GEY0R00
JA18 ERJ6GEY0R00
JA19 ERJ6GEY0R00
JA20 ERJ6GEY0R00
JA101 ERJ8GEY0R00
JA102 ERJ8GEY0R00
18
Description
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
COIL
LINE FILTER
LINE FILTER
FILTER
CERAMIC FILTER
CRYSTAL
CRYSTAL
CRYSTAL
CRYSTAL
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB 0.1W 5%
S.M.CARB .125W 5%
S.M.CARB .125W 5%
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
