English
Installation
Note:
The washing machine is equipped with
power cord and plug and needs sewage and
tap water connections. Before installation,
make sure that a suitable wall outlet is at the
desired place of installation.
Consider the dimensions (chapter Technical
data) of the product for placing and
installation.
Caution
• Before initial operation the transport
restraints must be removed from the
backside of the unit. Operating the
washing machine with mounted transport
restraints leads to serious damages.
• Keep the transport restraints for later
use. Never transport the device without
correctly mounted transport restraints!
Fig. Loosen the four transport restraints
1
with a wrench (13 mm) and unscrew
them completely. Insert the 4 supplied
blind plugs in the holes.
Place the washing machine on an even,
Fig.
2
horizontal and steady surface. For
levelling the feet are adjustable and can
be screwed in or out.
• Unscrew the lock nuts with an open-
end wrench (17 mm).
• Turn the feet to the right to screw
them in and to the left to unscrew
them.
• Use a spirit level to check whether
the appliance is levelled. If the
appliance is not standing horizontally
or is tilting the feet must be adjusted
again.
• If the unit is levelled and does not
tilt, tighten the nuts with the open-
end wrench.
30
IM_KWM7122B_INV_201118_V10_HR.indb 30 IM_KWM7122B_INV_201118_V10_HR.indb 30
Note:
Note the following, when placing the device
on a platform:
The device might move during spinning and
could fall of a platform. To prevent this, the
feet must be secured with retaining tabs
(available in specialized stores).
The washing machine must be
Fig.
3
connected to a drain.
• The drain hose is already fixed to the
sewage connection. Pull the hose out
of the clamps and unwind it.
• Connect the other end to the drain
pipe (option A or B). Observe the max.
height of the hose end.
Note:
• To avoid leakage, a hose clamp should be
used to correctly install the outlet hose.
• Suitable hose holders are available as
optional accessories.
Connect the water inlet to the water
Fig.
4
system (3/4 ") using the supplied
hose and make sure that everything
is connected correctly and firmly. The
water pressure must be between
0.05 MPa and 1 MPa. A pressure
reducing valve must be used if the
water pressure exceeds 1 MPa. The
correct installation of the water
connection should be checked on a
regular basis.
Note:
• If the water pipes are new or have not
been used for an extended period of time,
allow a certain amount of water to drain
until you are sure that the water is clear
and free of foreign objects.
• If this point is not observed, there is a risk
that the water inlet will become clogged
and the unit will be damaged.
Plug the mains plug into a suitable
Fig.
5
socket.
